Basic information
Environment Friendly Heat Shrinkable Tube uses specially designed formulation of high polymers, through cross-link by electronic accelerator and continuous expansion.
The properties of environment-friendly, flexibility flame retardant, quick shrink and stable performance make them widely used in the field of electronics, communication, automotive, pipeline protection and so on. It is widely applied for connecting or end-handing, electric wire, insulating and harness of electric wire, corrosion and rust-proof of metallic rods or tubes, gas pipeline and marking for other products.
| Item | CL-HFT | |
| Continuus Temperature Range | -40-125degrees | |
| Radial Shrinking Ratio | 2:1 3:1 | |
| Longitudinal Shrinking Ratio | ±5% | |
| Tensile Strength | ≥10.4MPa | |
| Elongation Ratio | ≥200% | |
| Aging in circulating-air oven | (158±1.0)ºC,7days | |
| After aging | Tensile Strength | ≥7.3MPa |
| Elongation Ratio | ≥100% | |
| Dielectric Voltage Withstand | 600V | |
| Corrosion of Bare Copper | ≥15kV/mm | |
| Flammability | VW-1 | |
| Concentricity | ≥65% | |
Special specifications and models can be customized.
Product DescriptionEnvironment Friendly Heat Shrinkable Tube uses specially designed formulation of high polymers, through cross-link by electronic accelerator and continuous expansion.
The properties of environment-friendly, flexibility flame retardant, quick shrink and stable performance make them widely used in the field of electronics, communication, automotive, pipeline protection and so on. It is widely applied for connecting or end-handing, electric wire, insulating and harness of electric wire, corrosion and rust-proof of metallic rods or tubes, gas pipeline and marking for other products.
