4. Completely seals, divulges for zeroMaterials
| STANDARD MATERIAL OF MAIN PARTS | ||
| NO. | PART | MATERIAL |
| 1 | Body | Cast Iron, Ductile Iron, Carbon Steel, Stainless Steel |
| 2 | Seat | NBR,EPDM, Viton,Neoprene,HYPALON,Silicon |
| 3 | Shaft | Stainless Steel416,316,304 |
| 4 | Disc | Ductile Iron+Ni,CF8,CF8M,Bronze |
| 5 | Pin | Stainless Steel |
| 6 | Bushing | PTFE,Bronze |
| 7 | O-Ring | NBR,EPDM |
Quick Details
Standard or Nonstandard: | Standard | Structure: | Butterfly | Pressure: | Medium Pressure |
Power: | Manual | Material: | Casting | Temperature of Media: | Medium Temperature |
Media: | Water | Port Size: | DN2"-60" | Place of Origin: | Tianjin China (Mainland) |
Model Number: | concentric butterfly valve | Brand Name: | WDS/OEM | Test: | API 598 |
Packaging & Delivery
Packaging Detail: | plastic or bubble bags, then plywood cases |
Delivery Detail: | 1 to 30 days according to the order |
**Features
-Simple and compact construction, quick 90 degree on-off operation, Minimized operating torque, energy saving.
-Bubbles-tight sealing with no leakage under the pressure test.
-The connection of driven part conforms to ISO 5211.
-Wide selection of materials, applicable for various medium.
-The valve body and disc are accurately machined which results in low operating torque and long service life and reliability.
-Can be disassembled, material-specific recycling possible.
-Can be installed at the end of pipe for lugged type butterfly valve.
**Technical data
Design:API 609\BS5155\EN593\GB/T12238\DIN3354
Face to Face:API609\ DIN3202 K1\BS5155\EN558\ISO5752\ASME B16.10
Flange End:ASME B16.1 CLASS 125\ASME B16.5 CLASS 150\ASME B16.47\BS EN 1092 PN6/PN10/PN16\JIS B 2220 5K/10K/16K\BS 10 Table D/Table E
Top Flange:ISO5211(According to customer's needs)
Inspection:API598\EN12266-1\ISO5208
Size Range:DN50-DN1600/2"-64"
Temperature:-40°C to +200°C (Depending on pressure, medium and material)
Medium:freshwater\ sewage\seawater\air\vapor\food\oils\medicine\ alcohol\salt
**Main Material List
BODY:CI, DI, WCB, WCC, LCB, LCC, CF8, CF8M, CF3, CF3M, C95400, C95800, SAF2205, SAF2507, F51, 1.4529...
SEAT:BUNA-N, NBR, EPDM, HYPALON, NEOPRENE, VITON, FKM, PTFE, RPTFE, TEFLON, NATURAL RUBBER...
DISC:CF8, 304, CF3, 304L CF8M, 316, CF3M, 316L, SAF2205, SAF2507, F51, 1.4529, C95400, C95500, C95800, MONEL..
STEM:F410, F420, F430, F431, F304, F316, MONEL 400, MONEL K500
About Factory
1. Factory History: more than 20 years
2. Factory Size: 1000-3000 squre meters
3. Factory Location: Jinnan District, Tianjin, China
4. Management Certification: ISO 9001:2000CE Others.
**General Applications
-Chemical and petrochemical industries.
-Water and wastewater technology.
-Pneumatic materials handling technology.
-Shipbuilding.
-Power generation industry.
-Food industry.
