Stainless Steel PTFE Lined Metal Hose with Flange DN8-600mm
Company Introduction
Company Introduction
We make all kinds of flex-related products, such as flexible metal hoses, expansion joints, braidings, hose fittings, and related machines,such as elastomer hose forming machine,hydraulic forming machine,wire braiding machine,rewinding machine,bellow forming machine, etc..We are lead manufacturer of flex-related products in China.
We supply metal hose and braid with the widest selection of products ranging from braided hose for value oriented customers to super flexible hoses to ultra-high pressure and high temperature hoses that satisfy industry's most demanding applications. Working closely with customers and suppliers helps us build quality products that meet or exceed compatibility and functional requirements, safety and environmental standards and deliver dependable, repeatable performance and value.
We supply metal hose and braid with the widest selection of products ranging from braided hose for value oriented customers to super flexible hoses to ultra-high pressure and high temperature hoses that satisfy industry's most demanding applications. Working closely with customers and suppliers helps us build quality products that meet or exceed compatibility and functional requirements, safety and environmental standards and deliver dependable, repeatable performance and value.
Product Description
The pipe has changed the characteristics that the pipe can not be bent by special processing methods. It can be used to connect the lower graphite and ceramic glass pipes, and can be used as the feeding and discharging pipe for tank trucks, tanks, containers or reaction still. It can be used for pipe misalignment or to balance pipe displacements, dimensional changes caused by climate or other reasons, or to eliminate high-frequency mechanical vibrations. Can also be used in special occasions such as tubular reactor or heat exchanger.
Production Description
| Product name | Stainless steel braided PTFE hose |
| Material | Stainless Steel 304, 321, 316 and 316L |
| DN | 8-600mm |
| Hose Type | Annular corrugated |
| Application | Water, gas and steam |
| Braided Mesh | Single / Double layer |
| Connect Type | Flange/Thread/Quick coupling |
Application:
The pipe has changed the characteristics that the pipe can not be bent by special processing methods. It can be used to connect the lower graphite and ceramic glass pipes, and can be used as the feeding and discharging pipe for tank trucks, tanks, containers or reaction still. It can be used for pipe misalignment or to balance pipe displacements, dimensional changes caused by climate or other reasons, or to eliminate high-frequency mechanical vibrations. Can also be used in special occasions such as tubular reactor or heat exchanger
1. HF01-1 normal type corrugated hose(We can provide DN10-150mm,length:20-20000mm F4,PVDF corrugated hose)
2. HF01-2 Pressure-resistant type corrugated hose with braiding
3. HF01-3 Corrugated hose with braiding and reinforced ring ,reinforced ring set in recess of F4 corrugated hose for negative pressure resistance
Connection type:
Flange connection,union connection,threaded connection,quick coupling and connect with pipe directly and fix it with a tube clip or metal wire. D
N4-32mm waveless braiding F4 crimping hose can be produced. Our factory can also provide corresponding connection method according to the user's requirements.
Parameter
| 15 | 20 | 25 | 32 | 40 | 50 | 57 | 65 | 73 | 80 | 89 | 100 | 114 | 125 | 150 | 200 |
| 15 | 20 | 25 | 33 | 38 | 51 | 57 | 63 | 73 | 80 | 89 | 100 | 114 | 125 | 159 | 219 |
| 30-50 | 40-60 | 50-70 | 60-80 | 60-100 | 100-150 | ||||||||||
| 17 | 22.4 | 27.6 | 35.8 | 40.8 | 54 | 60.2 | 66.2 | 76.4 | 83.6 | 92.6 | 105.8 | 117.8 | 129 | 164 | 225 |
| 10 | 15 | 20 | 25 | 30 | 40 | 45 | 52 | 63 | 68 | 75 | 90 | 102 | 113 | 140 | |
| 1.5 | 1.5 | 1.5 | 1.6 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2.1 | 2.2 | 2.5 | 2.6 | 3 |
| 0.65 | 0.62 | 0.6 | 0.5 | 0.5 | 0.5 | 0.4 | 0.3 | 0.25 | 0.23 | 0.2 | 0.18 | 0.12 | 0.08 | 0.07 | 0.05 |
| 1.6 | 1.6 | 1.6 | 1.6 | 1.6 | 1.6 | 1.2 | 1 | 1 | 0.8 | ||||||
| 2 | 2 | 2 | 2 | 2 | 2 | 1.5 | 1.2 | 1 | |||||||
| 90 | 85 | 80 | 75 | 70 | 65 | 63 | 61 | 60 | 58 | 56 | 50 | 30 | 20 | ||
| ≥5.0DN | ≥4.5DN | ≥4.0DN | ≥3.5DN | ≥3.0DN | 5DN | 5DN | |||||||||
| ≥5DN | 6DN | 6DN | |||||||||||||
| ≥5DN | 6DN | 6DN | |||||||||||||
| <150ºC | <100ºC | <100ºC | |||||||||||||
| -100ºC+150ºC | -10ºC~+120ºC | -0ºC | +80ºC | ||||||||||||
| -10ºC~+180ºC | -10ºC+160ºC | -5ºC~+150ºC | -0ºC | +80ºC | |||||||||||
| -5ºC~+180ºC | -5ºC+170ºC | -5ºC~+150ºC | -0ºC | +80ºC | |||||||||||
| ≥10.0000 normal temperature | left | left | |||||||||||||
| 200~20000mm | |||||||||||||||
FAQ
Q: Why so many suppliers choose us?
A:Because we are one of most professional manufacturer of the metal hose with more than 25 years of experience
Q:What sizes can you make?
A: all sizes from DN6 up to DN300
Q: What kind of fittings can you supply with the metal hose?
A: nuts, adapter, nipple, with BSP or NPT thread, we can customerized our hose according to your requirement
We need to know following information to give you our best quotation for the hoses:
A: Technical drawings
B: Material of the hose :sus304,321,316 or 316L
C: Material of the fittings, are they flange or pipe ends? Flange code?
D: Length and Diameter
E: Working pressure and temperature of the hose
F: Application of the hose
